Optical Biometer and Corneal Topographer Topcon MYAH

Key features:

• Optical biometry (LCI) with repeatable axial length tracking
• Corneal topography: 24-ring cone, 100,000+ analyzed points
• White-to-white and dynamic pupillometry
• Meibomian gland imaging for dry-eye assessment
• Contact lens fitting incl. RGP and Ortho-K databases
• Corneal aberrometry mapping
• Automated trend reports: axial length, refractive power, corneal power
• 10.1-inch capacitive touchscreen

Technical specifications:

• Keratoscopic cone: 24 rings on 43 D sphere
• Analyzed points: > 100,000
• Corneal coverage: up to 9.8 mm
• Diopter power range: 28.00–67.50 D
• Axial biometry: low-coherence interferometry (LCI)
• Axial length range: 15.00–36.00 mm
• AL repeatability: ± 0.03 mm
• Pupil range: 0.50–10.00 mm
• White-to-white: 8.00–14.00 mm
• Monitor: 10.1 inch LCD touchscreen
• Power: AC 100–240 V, 50/60 Hz, 100 VA
• Dimensions: 320 × 490 × 470 mm
• Weight: 18 kg
